FHR Series Ø255-650 Hydraulic Brake

FHR-255C

Application: Vertical & Horizontal

Installation Mode: Add-on

Table diameter(mm): Ø255

Table height (Horizontal)(mm): 290

Transmission Mechanisms: -

Rotation Allowable workpiece load (0˚Horizontal)(kg): 100

Rotation Allowable workpiece load (0˚~90˚Tilt)(kg): 75

FHR-255CL

Application: Vertical & Horizontal

Installation Mode: Add-on

Table diameter(mm): Ø255

Table height (Horizontal)(mm): 290

Transmission Mechanisms: -

Rotation Allowable workpiece load (0˚Horizontal)(kg): 100

Rotation Allowable workpiece load (0˚~90˚Tilt)(kg): 75

FHR-320

Application: Vertical & Horizontal

Installation Mode: Add-on

Table diameter(mm): Ø320

Table height (Horizontal)(mm): 355

Transmission Mechanisms: -

Rotation Allowable workpiece load (0˚Horizontal)(kg): 200

Rotation Allowable workpiece load (0˚~90˚Tilt)(kg): 150

FHR-320C

Application: Vertical & Horizontal

Installation Mode: Add-on

Table diameter(mm): Ø320

Table height (Horizontal)(mm): 310

Transmission Mechanisms: -

Rotation Allowable workpiece load (0˚Horizontal)(kg): 200

Rotation Allowable workpiece load (0˚~90˚Tilt)(kg): 100

FHR-400CF

Application: Vertical & Horizontal

Installation Mode: Add-on

Table diameter(mm): Ø400

Table height (Horizontal)(mm): 430

Transmission Mechanisms: -

Rotation Allowable workpiece load (0˚Horizontal)(kg): 200

Rotation Allowable workpiece load (0˚~90˚Tilt)(kg): 100

FHR-400C-540-HR400B

Application: Vertical & Horizontal

Installation Mode: Add-on

Table diameter(mm): Ø400

Table height (Horizontal)(mm): 380

Transmission Mechanisms: -

Rotation Allowable workpiece load (0˚Horizontal)(kg): 220

Rotation Allowable workpiece load (0˚~90˚Tilt)(kg): 120

FHR-401C-820-HR400B

Application: Vertical & Horizontal

Installation Mode: Add-on

Table diameter(mm): Ø400

Table height (Horizontal)(mm): 380

Transmission Mechanisms: -

Rotation Allowable workpiece load (0˚Horizontal)(kg): 220

Rotation Allowable workpiece load (0˚~90˚Tilt)(kg): 120

FHR-500C

Application: Vertical & Horizontal

Installation Mode: Add-on

Table diameter(mm): Ø500

Table height (Horizontal)(mm): 440

Transmission Mechanisms: -

Rotation Allowable workpiece load (0˚Horizontal)(kg): 500

Rotation Allowable workpiece load (0˚~90˚Tilt)(kg): 300

FHR-650C

Application: Vertical & Horizontal

Installation Mode: Add-on

Table diameter(mm): Ø650

Table height (Horizontal)(mm): 480

Transmission Mechanisms: -

Rotation Allowable workpiece load (0˚Horizontal)(kg): 500

Rotation Allowable workpiece load (0˚~90˚Tilt)(kg): 400
